24V 50Ah LiFePO4 LFP Prismatic Backup DC battery
- Long cycle life: up to 6000 life cycles @80% DOD
- Intelligent BMS Management
- For RVs, Trolling Motors, Solar, Off-grid, Energy Storage
- Group 31 Battery Size (L13xW6.77xH8.43 inches )
- Support 2S4P, up to 10.24kWh
- IATF 16949, BSCI, ISO 19001, 24001, 45001
- Metal fireproof shell, Safe design is better than sorry
| 25.6V 50Ah | 25.6V 105Ah | 25.6V 150Ah | 25.6V 200Ah | 25.6V 230Ah | |
|---|---|---|---|---|---|
|
Nominal Voltage (V)
|
25.6 |
25.6 |
25.6
|
25.6 |
25.6
|
|
Nominal Capacity (Ah)
|
50Ah |
105Ah |
150Ah |
200Ah |
230Ah |
|
Size (mm)
|
332x172x220 |
332x172x220 |
510x190x238 |
510x190x238 |
510x190x238 |
|
Weight (kg)
|
13.5 |
21 |
30 |
40 |
41
|
|
Charging Method
|
CC/CV
|
CC/CV
|
CC/CV
|
CC/CV |
CC/CV
|
|
Maximum Charging Current (A)
|
Max 0.5C @25℃
|
Max 0.5C @25℃
|
Max 0.5C @25℃
|
Max 0.5C @25℃
|
Max 0.5C @25℃
|
|
Charging Voltage (V)
|
29.2±0.20V |
29.2±0.20V |
29.2±0.20V |
29.2±0.20V |
29.2±0.20V |
|
Continuous Discharge Current (A)
|
50A
|
100A
|
150A
|
200A
|
200A |
|
Peak Discharge Current (A)
|
100A 10s @25℃
|
200A 10s @25℃
|
300A 10s @25℃
|
300A 10s @25℃
|
300A 10s @25℃
|
|
Discharge Cut-off Voltage (V)
|
20
|
20
|
20
|
20
|
20
|
|
Charge Temperature (℃)
|
0 ~ +50
|
0 ~ +50
|
0 ~ +50
|
0 ~ +50
|
0 ~ +50
|
|
Discharge Temperature (℃) |
-20 ~ +55
|
-20 ~ +55
|
-20 ~ +55
|
-20 ~ +55
|
-20 ~ +55
|
|
Shell Material |
SPCC
|
SPCC
|
SPCC
|
SPCC
|
|
|
Certification |
CE, RoHS, FCC, UL, UN38.3, MSDS |
CE, RoHS, FCC, UL, UN38.3, MSDS |
CE, RoHS, FCC, UL, UN38.3, MSDS |
CE, RoHS, FCC, UL, UN38.3, MSDS |
CE, RoHS, FCC, UL, UN38.3, MSDS |
24V 50Ah LiFePO4 Certificates
Complies with the health, safety, and environmental protection requirements
